The popularity and availability of faster information exchange systems such as Ethernet made the use of null-modem cables less common. Nowadays, such a cable can still be useful for kernel mode development, since it allows the user to remotely debug a kernel with a minimum of device drivers and code (a serial driver mainly consists of two FIFO buffers and an interrupt service routine). KGDB for Linux, ddb for BSD and WinDbg or KD for Windows can be used to remotely debug systems, for example. This can also provide a serial console through which the in-kernel debugger can be dropped to in case of kernel panics, in which case the local monitor and keyboard may not be usable anymore (the GUI reserves those resources and dropping to the debugger in the case of a panic won't free them).

The simplest type of serial cable has no hardware handshaking. This cable has only the data and signal ground wires connected. All of the other pins have no connection. With this type of cable flow control has to be implemented in the software. The use of this cable is restricted to data-traffic only on its cross connected Rx and Tx lines. This cable can also be used in devices that do not need or make use of modem control signals.

In this cable the flow control lines are still looped back to the device. However, they are done so in a way that still permits Request To Send (RTS) and Clear To Send (CTS) flow control but has no actual functionality. The only way the flow control signal would reach the other device is if the opposite device checked for a Carrier Detect (CD) signal (at pin 1 on a DE-9 cable and pin 8 on a DB-25 cable). As a result only specially designed software could make use of this partial handshaking. Software flow control still worked with this cable.

All the UARTs pins are TTL compatible. That includes TD, RD, RI, DCD, DSR, CTS, DTR and RTS which all interface into your serial plug, typically a D-type connector. Therefore RS232 Level Converters (which we talk about in detail later) are used. These are commonly the DS1489 Receiver and the DS1488 as the PC has +12 and -12 volt rails which can be used by these devices. The RS232 Converters will convert the TTL signal into RS232 Logic Levels.
